6. In table row "Cross section A …", read corresponding required cross
section
Country of use: International except for USA/Canada
Current I Nominal current fuse Cross section A
for installation type B1
A A
mm
2
1,6 2 1,5
Minimum cross section acc. to
EN 60204‑1:2006, table 5
(Main circuits; outside of hous‐
ings; permanently installed; sin‐
gle-core lines; stranded wire de‐
sign class 2)
3,3 4
5,0 6
8,6 10
10,3 16
13,5 16
18,3 20 2,5
22 25 4
28 32 6
31 40 6
35 40 10
44 50 10
59 63 16
77 80 25
96 100 35
117 125 50
149 160 70
180 200 95
208 250 120
227 250 150
257 315 185
301 355 240
342 400 300
Tab.15-2: Line Cross Sections and Fuses, B1 According to EN 60204-1:2006,
Table 6, as of 150mm² DIN IEC 60364-5-52:2004, Table B.52-4
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 267/309
Calculations
