Country of use: International except for USA/Canada
Current I Nominal current fuse Cross section A
for installation type B2
A A
mm
2
1,6 2 0,75
Minimum cross section acc. to
EN 60204‑1:2006, table 5
(Main circuits; outside of hous‐
ings; permanently installed; mul‐
ti-core lines)
3,3 4
5,0 6
8,5 10
10,1 16 1,0
13,1 16 1,5
17,4 20 2,5
23 25 4
28 32 6
30 40 6
35 40 10
40 50 10
54 63 16
70 80 25
86 100 35
103 125 50
130 160 70
156 200 95
179 200 120
195 224 150
221 250 185
258 315 240
294 355 300
Tab.15-3: Line Cross Sections and Fuses, B2 According to EN 60204-1:2006,
Table 6, as of 150mm² DIN IEC 60364-5-52:2004, Table B.52-4
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
268/309
Calculations
