Country of use: International except for USA/Canada
Current I Nominal current fuse Cross section A
for installation type E
A A
mm
2
1,6 2 0,75
Minimum cross section acc. to
EN 60204‑1:2006, table 5
(outside of housings; perma‐
nently installed; multi-core lines)
3,3 4
5,0 6
8,3 10
10,4 16
12,4 16 1
16,1 20 1,5
22 25 2,5
28 32 4
30 40 4
37 40 6
44 50 10
52 63 10
70 80 16
88 100 25
110 125 35
133 160 50
171 200 70
207 250 95
240 315 120
277 355 150
316 400 185
374 425 240
432 500 300
Tab.15-4: Line Cross Sections and Fuses, E According to EN 60204-1:2006, Ta‐
ble 6, as of 150mm² DIN IEC 60364-5-52:2004, Table B.52-10
