2-414-010 PTR:Normal:2nd:S3 *ENG [1 to 100 / 4 / 1/step]
165 mm > S3 size ≥ 139 mm
(Paper width)
2-414-011 PTR:Low:1st:S3 *ENG [1 to 100 / 36 / 1/step]
165 mm > S3 size ≥ 139 mm
(Paper width)
2-414-012 PTR:Low:2nd:S3 *ENG [1 to 100 / 77 / 1/step]
165 mm > S3 size ≥ 139 mm
(Paper width)
2-414-013 PTR:Normal:1st:S4 *ENG [1 to 100 / 22 / 1/step]
139 mm > S4 (Paper width)
2-414-014 PTR:Normal:2nd:S4 *ENG [1 to 100 / 79 / 1/step]
139 mm > S4 (Paper width)
2-414-015 PTR:Low:1st:S4 *ENG [1 to 100 / 35 / 1/step]
139 mm > S4 (Paper width)
2-414-016 PTR:Low:2nd:S4 *ENG [1 to 100 / 78 / 1/step]
139 mm > S4 (Paper width)
2421 [Plain:LE Correct] DFU
Adjusts the correction to the paper transfer roller current or discharge plate DC at the
paper leading edge in each mode. SP2403 and SP2407 are multiplied by these SP
values.
Normal/ Std: 260 mm/sec, Low: 85 mm/sec
• The paper leading edge area can be adjusted with SP2422.
5. System Maintenance Reference
316
