2448 [Plain2: TE Correct] DFU
Plain2: Trailing Edge Correction
Adjusts the correction coefficient to the paper transfer roller current for the paper
trailing edge of the plain 2 paper in each mode. SP2440 and SP2441 are multiplied
by these SP values.
Std: 260 mm/sec, Low: 85mm/sec
• The paper trailing edge area can be adjusted with SP2449.
2-448-001 PTr:Std:1 *ENG [0 to 995 / 100 / 5 %/step]
2-448-002 PTr:Std:2 *ENG
2-448-003 PTr: Low: 1st *ENG
2-448-004 PTr: Low: 2nd *ENG
2-448-005 SepaDC:Std:1st *ENG
2-448-006 SepaDC:Std:2nd *ENG
2-448-007 SepaDC:Low:1st *ENG
2-448-008 SepaDC:Low:2nd *ENG
2449 [Plain2:SW Tmng:TE] DFU
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at
the paper trailing edge of the plain 2 paper between the erase margin area and the
image area.
Standard: 260 mm/sec, Low: 85mm/sec
5. System Maintenance Reference
328
