2-703-002 PTr:StdSpd:2nd *ENG [0 to 230 / 18 / 1- A /step]
2-703-003 PTr:LowSpd:1st *ENG [0 to 230 / 10 / 1- A /step]
2-703-004 PTr:LowSpd:2nd *ENG [0 to 230 / 12 / 1- A /step]
2707 [MThick:Bias:FC]
Standard: 260mm/sec, Low: 85mm/sec
Adjusts the current for the paper transfer roller for middle thick in full color mode.
2-707-001 PTr:StdSpd:1st *ENG [0 to 230 / 35 / 1- A /step]
2-707-002 PTr:StdSpd:2nd *ENG [0 to 230 / 25 / 1- A /step]
2-707-003 PTr:LowSpd:1st *ENG [0 to 230 / 12/ 1- A /step]
2-707-004 PTr:LowSpd:2nd *ENG [0 to 230 / 14 / 1- A /step]
2713 [MThick: SzCor: BW] DFU
Adjusts the size correction coefficient for the paper transfer roller current for each
paper size. SP2703 and SP2707 are multiplied by these SP values.
Standard: 260mm/sec, Low: 85mm/sec
2-713-001 PTr:Std:1Sid:S1 *ENG [100 to 995 / 100 / 5%/step]
S1 size ≥ 194 mm (Paper width)
2-713-002 PTr:Std:2Sid: S1 *ENG
2-713-003 PTr:Low:1:S1 *ENG
2-713-004 PTr:Low:2:S1 *ENG
2-713-005 PTr:Std:1Sid:S2 *ENG [100 to 995 / 135 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
2-713-006 PTr:Std:2Sid:S2 *ENG [100 to 995 / 200 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
2-713-007 PTr:Low:1:S2 *ENG [100 to 995 / 135 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
Engine SP Mode Tables - SP2000
361
