2773 [SP 1:TE Correct] DFU
Special 1 Paper: Trailing Edge Correction
Adjusts the correction to the paper transfer roller current for the paper trailing edge in
each mode. SP2753 and SP2757 are multiplied by these SP values.
Standard: 260 mm/sec, Low: 85 mm/sec
• The paper trailing edge area can be adjusted with SP2774.
2-773-001 PTr:Std:1 *ENG [0 to 995 / 100 / 5%/step]
2-773-002 PTr:Std:2 *ENG
2-773-003 PTr: Low: 1st *ENG
2-773-004 PTr: Low: 2nd *ENG
2-773-005 SepaDC:Std:1st *ENG
2-773-006 SepaDC:Std:2nd *ENG
2-773-007 SepaDC:Low:1st *ENG
2-773-008 SepaDC:Low:2nd *ENG
2774 [SP 1:SW Tmng:TE] DFU
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at
the paper trailing edge between the erase margin area and the image area.
Standard: 260 mm/sec, Low: 85 mm/sec
2-774-001 PTr:Std:1st *ENG [0 to 50 / 0 / 2 mm/step]
2-774-002 PTr:Std:2nd *ENG
2-774-003 PTr: Low : 1st *ENG
2-774-004 PTr: Low : 2nd *ENG
2-774-005 SepaDC:Std:1st *ENG
2-774-006 SepaDC:Std:2nd *ENG
2-774-007 SepaDC:Low:1st *ENG
2-774-008 SepaDC:Low:2nd *ENG
5. System Maintenance Reference
378
