2780 [SP 1: EnvCor] DFU
Standard: 260 mm/sec, Low: 85 mm/sec
2-780-013 SepaDC:Std:1st *ENG [1 to 100 / 30 / 1 /step]
Adjusts the size correction coefficient
table of the special 1 paper for the
discharge plate DC for each printing
side.
2-780-014 SepaDC:Std:2nd *ENG
2-780-015 SepaDC:Low:1st *ENG
2-780-016 SepaDC:Low:2nd *ENG
[SP 1:Ed-Env.Cor] DFU
2-780-017 SepaDC:Std:1st *ENG [1 to 100 / 50 / 1 /step]
Adjusts the size correction coefficient
table of the special 1 paper for the
discharge plate DC (leading and traiing
edges) for each printing side.
2-780-018 SepaDC:Std:2nd *ENG
2-780-019 SepaDC:Low:1st *ENG
2-780-020 SepaDC:Low:2nd *ENG
2801 [Special 2: Bias]
Adjusts the DC voltage of the discharge plate for special paper 2.
Middle: 182 mm/sec, Low: 85 mm/sec
2-801-001 SepaDC:MidSpd:1st *ENG [0 to 6000 / 2000 / 10 -V /step]
2-801-002 SepaDC:MidSpd:2nd *ENG
2-801-003 SepaDC:LowSpd:1st *ENG
2-801-004 SepaDC:LowSpd:2nd *ENG
2803 [SP 2: Bias: BW]
Adjusts the current for the paper transfer roller for special paper 2 in black-and-white
mode.
Middle: 182 mm/sec, Low: 85 mm/sec
2-803-001 PTr:MidSpd:1st *ENG [0 to 230 / 15 / 1 – A /step]
2-803-002 PTr:MidSpd:2nd *ENG
2-803-003 PTr:LowSpd:1st *ENG [0 to 230 / 9 / 1 – A /step]
2-803-004 PTr:LowSpd:2nd *ENG [0 to 230 / 12 / 1 – A /step]
Engine SP Mode Tables - SP2000
379
