2807 [SP2: Bias: FC]
Adjusts the current for the paper transfer roller for special paper 2 in full color mode.
Middle: 182 mm/sec, Low: 85 mm/sec
2-807-001 PTr:MidSpd:1st *ENG [0 to 230 / 24 / 1 – A /step]
2-807-002 PTr:MidSpd:2nd *ENG
2-807-003 PTr:LowSpd:1st *ENG [0 to 230 / 12 / 1 – A /step]
2-807-004 PTr:LowSpd:2nd *ENG [0 to 230 / 18 / 1 – A /step]
2811 [SP 2: SzCor: BW] DFU
Adjusts the size correction coefficient for the paper transfer roller current for each
paper size. SP2803 and SP2807 are multiplied by these SP values.
Middle: 182 mm/sec, Low: 85mm/sec
2-811-001 PTr:Mid:1Sid:S1 *ENG [100 to 995 / 100 / 5%/step]
S1 size ≥ 194 mm (Paper width)
2-811-002 PTr:Mid:2Sid: S1 *ENG
2-811-003 PTr:Low:1:S1 *ENG
2-811-004 PTr:Low:2:S1 *ENG
2-811-005 PTr:Mid:1Sid:S2 *ENG [100 to 995 / 150 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
2-811-006 PTr:Mid:2Sid:S2 *ENG [100 to 995 / 160 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
2-811-007 PTr:Low:1:S2 *ENG [100 to 995 / 150 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
2-811-008 PTr:Low:2:S2 *ENG [100 to 995 / 160 / 5%/step]
194 mm > S2 size ≥ 165 mm (Paper
width)
