Rinstrum R427 User Manual

Reference Manual Rev 1.13
004R-646-113 Page 117
19.3. Tokens
Tokens are special ASCII characters outside the normal printing range. These
characters are used to specify where instrument data fields like ‘Current Weight’ are
to be inserted into custom format strings.
19.3.1. Non-paged generic tokens
Code Token
128
(80
H
)
ASCII NULL (send an ASCII 00H character)
191
(BF
H
)
Date
192
(C0
H
)
Time (24H format)
193
(C1
H
)
Newline
194
(C2
H
)
Left spaces
195
(C3
H
)
Top blank lines
196
(C4
H
)
Bottom blank lines
197
(C5
H
)
Unique consecutive print ID
198
(C6
H
)
Header
199
(C7
H
)
Footer
200
(C8
H
)
Page end string
201
(C9
H
)
User String Data 1
202
(C
A
H
)
User String Data 2
203
(CB
H
)
User String Data 3
204
(CC
H
)
User String Data 4
205
(CD
H
)
User String Data 5
206
(CE
H
)
User String Name 1
207
(CF
H
)
User String Name 2
208
(D0
H
)
User String Name 3
209
(D1
H
)
User String Name 4
210
(D2
H
)
User String Name 5
211
(D3
H
)
Time (12H format)
213
(D5
H
)
Settable consecutive print ID
214
(D6
H
)
Reset to 1 the settable consecutive print ID
Table 9: Print tokens: generic
19.3.2. Page tokens
As there is too much data to represent as individual tokens so the tokens are divided
up into pages. A page token is used to define the page for all subsequent tokens.
Code Token
190
(BE
H
)
Page 0: Current Weight
189
(BD
H
)
Page 1: Held Weight
188
(BC
H
)
Page 2: Held or Current Weight
187
(BB
H
)
Page 3: Traceable Weight
186
(BA
H
)
Page 4: Current Product
185
(B9
H
)
Page 5: Session Total
184
(B8
H
)
Page 6: Grand Total
183
(B7
H
)
Page 7: Register Data
182
(B6
H
)
Page 8: Miscellaneous weight data
180
(B4
H
)
Page 10: Default print strings
Table 10: Print tokens: pages
