Reference Manual Rev 1.13
004R-646-113 Page 83
12.10.13. DYN.SCL (Dynamic reading scaling factor)
Path Description
AXLE
└ DYN.SCL
Scaling factor for dynamic weights.
Values <NUM>
0.500000 .. 2.000000
Default 1.000000
12.10.14. I/LOCK (Truck weighing interlock)
Path Description
AXLE
└ I.LOCK
Input for interlock, must be high for the entire truck.
If set, this input must remain high throughout the
entire truck capture. The truck will be finished as
soon as the input goes low. If the input goes low
during an axle capture then you will get an error.
Values <OPT>
NONE
(Default)
, IO1 .. IO32
12.10.15. IL.TIME (Truck weighing interlock time)
Path Description
AXLE
└ IL.TIME
If set it will limit the time the truck can take. If this is
set then the complete truck weighing must be
completed before the time set or you will get an
error.
Values <NUM>
0.00 .. 60.00 s
Default 0
12.10.16. USE IO
Path Description
AXLE
└ USE IO
Use IOs or not for starting/stopping the axle
weighing.
Values <OPT>
ON
(Default)
, OFF
12.11. End (Save and exit)
