Reference Manual Rev 1.13
Page 80
004R-646-113
12.9.
AXLE (K405)
12.9.1.
MIN.WGT (Minimum weight)
Path
Description
AXLE
└
MIN.WGT
The minimum axle weight.
Values
<NUM>
0 .. 999999
Default 500
12.9.2.
IDLE (Idle time)
Path
Description
AXLE
└
IDLE
How long to wait for next axle.
Values
<NUM>
0.00 .. 60.00 s
Default 5.00 s
12.9.3.
MODE (Capture mode)
Path
Description
AXLE
└
MODE
Weighing mode.
Values
<OPT>
STATIC
(Default)
, OFF
79
81
