14.6. rinCMD Examples
Description
Read Gross Weight
( Read Final)
COMMAND:
Read Gross Weight (Register 0026):
ADDR = 20
H :
Reply required from any instrument
CMD = 11
H
: Read Final
REG = 0026
H
: Gross Weight
RESPONSE:
Response is from instrument #1 which currently has
a Gross weight of 64
H
= 100 kg.
COMMAND:
20110026
RESPONSE:
81110026:00000064
Read Gross Weight
(Read Literal)
COMMAND:
Read Gross Weight (Register 0026
H
):
ADDR = 20
H :
Reply required from any instrument
CMD = 05
H
: Read Literal
REG = 0026
H
: Gross Weight
RESPONSE:
Same response from instrument #1 but in literal
format.
COMMAND:
20050026
RESPONSE:
81050026: 100 kg G
Set Print Header
(Write Final, Execute)
COMMAND A:
Write Print Header String (Register A381
H
)
ADDR = 21
H :
Reply required from instrument #1
CMD = 12
H
: Write Final
REG = A381
H
: Print Header String
DATA = ‘Hello There’
RESPONSE A:
Instrument #1 reports “ERROR: Access Denied”.
(Writing to this register requires a passcode)
COMMAND B:
Enter SAFE SETUP Passcode (Register 1A
H
)
ADDR = 21
H :
Reply required from instrument #1
CMD = 12
H
: Write Final
REG = 1A
H
: Enter SAFE PASSCODE
DATA = 4D2
H
(passcode is 1234)
RESPONSE B:
Instrument #1 reports Passcode Accepted
COMMAND C: (resend COMMAND A).
RESPONSE C:
Instrument #1 reports ”Command Successful”.
COMMAND D:
Save Settings (Register 10
H
)
ADDR = 21
H :
Reply required from instrument #1
CMD = 10
H
: Execute
REG = 10
H
: Save Settings
RESPONSE D:
Instrument #1 reports ”Command Successful”.
COMMAND A:
2112A381:Hello There
RESPONSE A:
C112A381:9000
COMMAND B:
2112001A:4D2
RESPONSE B:
8112001A:0000
COMMAND C:
2112A381:Hello There
RESPONSE C:
8112A381:0000
COMMAND D:
21100010
RESPONSE D:
81100010:0000
