Rinstrum R427 User Manual

Reference Manual Rev 1.13
004R-646-113 Page 97
Description
Trigger Zero Button
Press
(Write Final)
COMMAND A:
Send down the Zero button key code.
RESPONSE A:
Instrument #1 reports ”Command Successful”.
COMMAND B:
Do a long press of the F1 key.
RESPONSE B:
Instrument #1 reports ”Command Successful”.
COMMAND A:
21120008:0B
RESPONSE A:
81120008:0000
COMMAND B:
21120008:8E
RESPONSE B:
81120008:0000
Streaming
(Write Final, Read Final,
Execute)
COMMAND A:
Setup to read the displayed weight.
RESPONSE A:
Instrument #1 reports ”Command Successful”.
COMMAND B:
Setup to read the IO status.
RESPONSE B:
Instrument #1 reports ”Command Successful”.
COMMAND C:
Read the combined data.
RESPONSE C:
Data is concatenated. It is 8 hexadecimal digits
each.
COMMAND D:
Set streaming to 3Hz.
RESPONSE D:
Instrument #1 reports ”Command Successful”.
COMMAND E:
Start the automatic streaming.
RESPONSE E:
Instrument #1 reports ”Command Successful”
followed by streamed data at 3Hz.
COMMAND G:
Stop the automatic streaming.
RESPONSE G:
Instrument #1 reports ”Command Successful”.
COMMAND A:
21120042:06
RESPONSE A:
81120042:0000
COMMAND B:
21120043:11
RESPONSE B:
81120043:0000
COMMAND C:
21110040
RESPONSE C:
81110040:000005DB000
00009

COMMAND D:
21120041:03
RESPONSE D:
81120041:0000
COMMAND E:
21100040:1
RESPONSE E:
81100040:00000000
81110040:000005DB000
00009
81110040:000005DB000
00009

COMMAND G:
21100040:0
RESPONSE G:
81100040:00000000
