Rinstrum R427 User Manual

Reference Manual Rev 1.13
Page 60 004R-646-113
12.2.2. SER1.HW, SER2.HW
Path Description
H.WARE
└ SER1.HW
└ BAUD
└ PARITY
└ DATA
└ STOP
└ DTR
└ TERM
└ SER2.HW
└ BAUD
└ PARITY
└ DATA
└ STOP
└ DTR
└ TERM
└ RING
BAUD (Baud Rate)
Sets the baud rate for the port.
PARITY
Sets the parity for the port.
DATA (Data bits)
Sets the number of data bits for the port.
STOP (Stop bits)
Sets the number of stop bits for the port.
DTR (DTR usage)
Use the DTR line with RS232 printing.
TERM (Termination Resistors)
Use termination resistors with RS485.
RING (Ring network)
Enable ring network. Only available on SER2 and
requires M42xx software version 1.01+.
BAUD Values <OPT>
_1200_ , _2400_ , _4800_,
_9600_
(Default)
, _19200_,
_57600_
PARITY Values <OPT>
NONE
(Default)
, EVEN, ODD
DATA Values <OPT>
_8_
(Default)
, _7_
STOP Values <OPT>
_1_
(Default)
, _2_
DTR Values <OPT>
OFF
(Default)
, ON
TERM Values <OPT>
OFF
(Default)
, ON
RING Values <OPT>
OFF
(Default)
, ON
