Installing Communication Modules
Plug in GSM
Module
(front and back)
Plug in IP Module
(front and back)

SIM holder on GSM module

Antenna for GSM module (shown with internal antenna installed)

GSM module

IP module

Network cable connector on IP module (shown with cable connected)

AC or DC power cable (shown installed from the back of the main
panel)






