Page 10
Chapter 3: Describing and Using the Main Panel
WiComm Pro Main Components

Back tamper screw location

Wiring channel for network
cable (shown with cable routed
via hook)

Opening for AC or DC power
cable (cable is installed onto
the back of the panel only
after the mounting bracket is
secured to the wall)

Front access cover

LED indicators

Locking-screws (2)






