I/O Expander: Wired Zones
• Normal (Default): 2.5 minutes dead time between alarm detections transmissions
• Fast (Walk Test): Alarm detection is immediately transmitted
Output Parameters
The I/O Expander has 4 physical outputs on board: 2 relays (3 amp), and 2 transistor
outputs (500 mA)
I/O Expander: Output Parameters
A label identifies the output in the system.
There are 5 “types” of outputs in the system as follows
• Not Used
• Follow System: The utility output will follow a system event
• Follow Partition: The utility output will follow a partition event
• Follow Zone: The utility output will follow a zone event. Each utility output can be
activated by a group of up to five zones
• Follow Code: The utility output will be activated by a user defined as UO Control or
from the user programming menu
Activates when a bell is triggered. If a bell delay was defined, the utility output
will be activated after the delay period.
Monitoring Station Communication Fail
Activates when communication with the Central Monitoring Station cannot be
established.
Deactivates after a successful call is established with the Monitoring Central
Station.
Activates when a system trouble condition is detected.
Deactivates after the trouble has been corrected
Activates when the Pro battery has insufficient reserve capacity and the
voltage decreases to 6V.
