Risco RW332M - Page 81

Page 75
I/O Expander: Wired Zones
Parameter
Default
Range
Define whether the zone can be force armed or not. For more information refer
to page 57.
No Activity
Determines whether the zone participates in the No Activity function. The No
Activity function is for reception of signals used to monitor the activity of sick,
elderly or disabled people. For more information refer to page 57.
Abort Alarm
This parameter defines whether a zone alarm report to the monitoring station
will be immediate or delayed. For more information refer to page 58.
Termination
The Termination menu enables you to program the connection type used for the wired
zones 33-36. The actual (physical) termination for each zone must comply with that
selected in the zone termination menu.
• N/C (Normally Closed): Uses normally-closed contacts and no terminating end-of-line
resistor
• N/O (Normally Open): Uses normally-open contacts and no terminating end-of-line
resistor
• EOL(End of Line): Uses normally-closed (N/C) and/or normally-open (N/O) contacts
in a zone terminated by a supplied 2200 (2200 ohm) end-of-line resistor
Loop response
Loop Response menu enables you to set the different times for which a wired zone
violation must exist before the zone will trigger an alarm condition.
The following option are available:
Normal 400 ms
0.5 hours
2 hours
3.5 hours
Slow: 1 second
1 hour
2.5 hours
4 hours
Fast: 10 ms
1.5 hours
3 hours
