Roland VR-6HD

139
Menu List
Menu item
Value (bold text: default
value)
Explanation
PANEL LOCK
Enable (ON) or disable (OFF) the panel lock.
Menu item Explanation
ALL
The following settings are
turned on/o together.
TOUCH SCREEN Touch panel operation
VIDEO SWITCHER ALL Buttons in VIDEO section
VIDEO SWITCHER 1–6
BUTTON
VIDEO SWITCHER [1]–[6]
buttons
CUT BUTTON [CUT] button
AUTO BUTTON [AUTO] button
MODE ALL Buttons in MODE section
INPUT SELECT
BUTTON
[INPUT SELECT] button
AUX BUTTON [AUX] button
SCENE MEMORY
BUTTON
[SCENE MEMORY] button
MACRO BUTTON [MACRO] button
TRANSITION ALL Buttons in TRANSITION section
MIX BUTTON [MIX] button
WIPE BUTTON [WIPE] button
SPLIT BUTTON [SPLIT] button
PinP & KEY 1–2 ALL
Buttons in PinP & KEY 1–2
section
PVW BUTTON PinP & KEY 1–2 [PVW] button
PGM BUTTON PinP & KEY 1–2 [PGM] button
POSITION H KNOB [POSITION H] knob
POSITION V KNOB [POSITION V] knob
DSK ALL Buttons in DSK section
PVW BUTTON DSK [PVW] button
PGM BUTTON DSK [PGM] button
MONITOR BUTTON [MONITOR] button
PANEL SETUP BUTTON PANEL [SETUP] button
OUTPUT FADE BUTTON [OUTPUT FADE] button
Menu item Explanation
AUDIO MIXER 1–7/8 ALL
Buttons and knobs in AUDIO
INPUT section
SETUP BUTTON SETUP [1]–[7/8] buttons
SOLO BUTTON SOLO [1]–[7/8] buttons
MUTE BUTTON MUTE [1]–[7/8] buttons
LEVEL FADER LEVEL [1]–[7/8] faders
MAIN ALL
Buttons and knobs in AUDIO
OUTPUT section
SETUP BUTTON MAIN [SETUP] button
MUTE BUTTON MAIN [MUTE] button
LEVEL FADER MAIN [LEVEL] fader
AUX 1 KNOB [AUX 1] knob
AUX 2 KNOB [AUX 2] knob
USB STREAM KNOB [USB STREAM] knob
STREAM/RECORD KNOB [STREAM/RECORD] knob
AUDIO EFFECT ALL
Buttons in AUDIO EFFECT
section
SETUP BUTTON AUDIO EFFECT [SETUP] button
AUDIO EFFECT 1–3
BUTTON
AUDIO EFFECT [1]–[3] button
AUDIO PLAYER ALL
Buttons in AUDIO PLAYER
section
SETUP BUTTON AUDIO PLAYER [SETUP] button
AUDIO PLAYER 1–6
PAD
AUDIO PLAYER [1]–[6] pads
AUDIO PLAYER KNOB AUDIO PLAYER [LEVEL] knob
AUX LINKED PGM
Species whether the same video as the nal output is sent to the AUX bus (AUX link).
OFF
Use the VIDEO SWITCHER [1]–[6] buttons to select the video of the AUX bus.
When selecting a video that is not assigned to INPUT 1–6, set this in “AUX SOURCE” under the
VIDEO ASSIGN menu.
AUTO LINK
MANUAL LINK
AUX link is enabled, and the same video as the nal output is sent to the AUX bus.
Temporarily disabling AUX link
When you press a VIDEO SWITCHER [1]–[6] button, the selection of the VIDEO SWITCHER [1]–
[6] button is enabled (lit green). You can select the video you want to send to the AUX bus.
Re-enabling AUX link
AUTO LINK
When you operate the [AUTO] button etc. to switch the nal output
video, AUX link is automatically enabled.
MANUAL LINK
When you press the VIDEO SWITCHER [1]–[6] button that is currently
selected (lit green), AUX link is enabled.
OUTPUT FADE ASSIGN Species the function of the [OUTPUT FADE] button.
OUTPUT FADE TIME 0.0–1.0–4.0sec Sets the fade-in/out time.
OUTPUT FADE ASSIGN VIDEO N/A, BLACK, WHITE, AUX The nal output video is faded-in/out to the specied video.
OUTPUT FADE ASSIGN
AUDIO
DISABLE, ENABLE When this is set to “ENABLE”, the output audio also fades in/out along with the video.
