IIT-2000/2010/5000/5010 Instruction Manual/English
108 05/08/2015 Version No. 001
compose the automatic test:
Each step must be passed for a PASS judgment (excluding
skipped tests).
A FAIL result for a single step will result in FAIL for the whole
automatic test.
A STOP. No step can be stopped for a PASS/FAIL judgment to
be made. In other words, if a test is stopped, it is judged as
neither PASS nor FAIL.
No step can contain an ERROR or ILOCK message.
E R R
P A S
O
S
P A S
S K I
S
P
E MA U OT N A_ 1A U T O = 0 0 1 - 0 0
# 0 1 : # 0 2 : # 0 3 :
# 0 5 : # 0 6 : # 0 7 : # 0 8 : S T O
# 0 9 : # 1 0 : # 1 1 : # 1 2 :
# 1 3 : # 1 4 : # 1 5 : # 1 6 :
P
I L O
F A I
C
L
ILOCK messageERROR message
R K
ERROR: Indicates that V, I or R is not correct. This usually
occurs if the testing leads are not properly connected.
ILOCK: Indicates that the interlock key is disconnected (if
configured to be used).
When all the tests have been judged as PASS, the
PASS indicator will be lit green and the buzzer will
sound.
To Next Page
