PASS / FAIL MANU Test
Background
If the test is allowed to run to completion (the test is not
stopped or a protection setting is not tripped) then the tester
will judge the test as either PASS or FAIL.
Note
The test will be judged PASS when:
 The HI SET and LO SET limits have not been tripped during
the test time.
The test will be judged FAIL when:
 Either the HI SET or LO SET limit has been tripped during
the test time.
 A protection setting has been tripped during the test time.
See page 198 for a list of error messages.
PASS Judgment
1. When the test is judged as PASS, PASS will be
displayed, the buzzer will sound and the PASS
indicator will be lit green.
PASS
I R G B A CW D C W
E
F R E Q = 0 H z 6
0 100
k V
SAP
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
MM A UN N A_2M A N U = * * * - 0 0
S
m A
00 37
2. The PASS judgment will be held on the display until the STOP
or START button is pressed.
