RS PRO IIT-2000 - SWEEP:Graph:line

IIT-2000/2010/5000/5010 Instruction Manual/English
182 05/08/2015 Version No. 001
Parameter/
Return
parameter
ON
Turn the sweep graph on.
OFF
Turn the sweep graph off.
Example
SWEEP:GRAP:SHOW ON
Displays the sweep graph on the LCD display.
SWEEP :GRAPh:LINE
Set
Query
Description
Sets or returns which lines are shown on the sweep graph.
Syntax
Query Syntax
SWEEP:GRAPh:LINE <NR1>
SWEEP:GRAPh:LINE?
Parameter/
Return
parameter
<NR1>
Description
0
Turn all lines off/all lines are off.
1
Displays the graph line for the primary test item. See
page 87 for details.
For example: V for ACW, DCW and IR tests, I for GB
tests.
2
Displays the graph line for the secondary test items.
For example: I for ACW and DCW tests, R for IR and
GB tests.
3
Turn all lines on/all lines are on.
