RS PRO IIT-2000 - Sweep:graph:show

IIT-2000/2010/5000/5010 Instruction Manual/English
05/08/2015 Version No. 001 181
Query Syntax
SWEEP<X>:DATA:SHOW?
Parameter
<X>
<NR1> 1~190 (single data point)
<X>
<NR1> 0 (all data points)
Single Data
Point Example
SWEEP10:DATA:SHOW?
> 010,0.106,00.00,0001.0, CR+LF
Returns the data at point 10, which is at the 1 second time for the
sweep test.
All Data Points
Example
SWEEP0:DATA:SHOW?
>ACW MODE,CR+LF
>No.,V(kV),I(mA), T(S) ,CR+LF
>001,0.071,0.032,0000.1,CR+LF
>002,0.111,0.047,0000.2,CR+LF
>…………………………………
>013,0.601,0.215,0001.3,CR+LF
>END
This will return all the data from the sweep graph.
SWEEP:GRAPh:SHOW
Set
Query
Description
Turns the sweep graph on or off on the IIT-5010/5000 display.
Syntax
Query Syntax
SWEEP:GRAPh:SHOW {ON|OFF}
SWEEP:GRAPh:SHOW?
