RS PRO IIT-2000 - ACW, DCW, IR and GB Manual Testing

IIT-2000/2010/5000/5010 Instruction Manual/English
42 05/08/2015 Version No. 001
ACW, DCW, IR and GB Manual Testing
This section describes how to create, edit and run a single ACW, DCW, IR or GB
safety test. Each Manual setting described in this chapter only applies to the
selected manual test – no other manual tests are affected.
Each manual test can be stored/recalled to/from one of 100 memory locations.
Each stored manual test can be used as a test step when creating an AUTO test
(page 92).
 Choose/Recall a Manual Test number → from page 44.
 Edit Manual Test Settings → from page 45.
 Setting the Test Function→ from page 46.
 Setting the Test Voltage or Test Current→ from page 47.
 Setting the Test Frequency → from page 48.
 Setting the Upper and Lower Limits → from page 49.
 Setting a Reference Value → from page 52.
 Setting the Test Time (Timer) → from page 53.
 Setting the Ramp Up Time → from page 55.
 Creating a MANU Test File Name→ from page 56.
 Setting the ARC Mode → from page 58.
 Setting PASS HOLD→ from page 62.
 Setting FAIL MODE→ from page 63.
 Setting MAX HOLD→ from page 65.
