RS PRO IIT-2000 - Automatic Test Results

IIT-2000/2010/5000/5010 Instruction Manual/English
05/08/2015 Version No. 001 107
Exit Testing
To exit testing, press the MANU/AUTO key when
the tester is in the READY status. The tester will
revert to the VIEW status for the current
automatic test.
MANU/AUTO
I R G B A CW D C W
E
F R E Q = 0 H z 6
0 100
k V
EIV
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
W
MA U OT N A_0A U T O = 0 0 1 - 1 0
m A
Automatic Test Results
Background
If all the test steps are allowed to run to completion (the AUTO
test is not stopped or a protection setting is not tripped) then
the tester will judge each step as either PASS or FAIL. This is
shown as a table after the automatic test has finished running.
If the test has been stopped, then any remaining tests will not
be run and thus the AUTO test will not finish running.
Overview
P A S
P A S
S
S
P A S
S K I
S
P
E MA U OT N A_ 1A U T O = 0 0 1 - 0 0
# 0 1 : # 0 2 : # 0 3 : # 0 4 : P A S
# 0 5 : # 0 6 : # 0 7 : # 0 8 : S T O
# 0 9 : # 1 0 : # 1 1 : # 1 2 :
# 1 3 : # 1 4 : # 1 5 : # 1 6 :
S
P
F A I
F A I
L
L
FAIL judgmentPASS judgment
skipped step step stopped
Note
The PASS/FAIL judgment for an automatic test as a whole
depends on the results of all the steps (manual tests) that
