IIT-2000/2010/5000/5010 Instruction Manual/English
106 05/08/2015 Version No. 001
Stop a Running
Test
1. To stop the AUTO test at any time when it is
running, press the STOP button. The AUTO test
will stop immediately. When the STOP button is
pressed, a judgment is not made on the current
test and any remaining tests are aborted.
All panel keys except the STOP and START
buttons are locked when the tester has been
stopped. All the results up until when the AUTO
test was stopped are shown on-screen. See
page 107 for more details on automatic test
results.
STOP
E MA U OT N A_ *A U T O = 0 0 1 - * *
# 0 1 : F A I # 0 2 : P A S # 0 3 : S T O # 0 4 : - - -
# 0 5 : - - - # 0 6 : - - - # 0 7 : - - - # 0 8 : - - -
# 0 9 : # 1 0 : # 1 1 : # 1 2 :
# 1 3 : # 1 4 : # 1 5 : # 1 6 :
L
-
S
-
P
-
-
-
Example of an automatic test that has been stopped. Dashes
(-) indicate aborted test steps.
2. To put the tester back into READY status, press
the STOP button again.
STOP
