IIT-2000/2010/5000/5010 Instruction Manual/English
150 05/08/2015 Version No. 001
Example
FUNC:TEST ON
Turns the output on.
MEASure<x>
Query
Description
Returns the test parameters & results of the tester in either
MANU or AUTO mode.
MANU mode: Returns the test parameters & results of a MANU
test.
AUTO mode: Returns the test parameters & results of the
selected step (1-16) of the AUTO test.
Return parameters: function, judgment/status, test voltage, test
current/resistance, test time (time of completed test) or ramp time
(elapsed time of test that has not been completed.
Query Syntax
MEASure<x>?
Parameter
(MANU mode)
No parameter needed for MANU mode.
Parameter
(AUTO mode)
<x>
<NR1>1~16. Step number.
Return
parameter
<string>
Returns the test status of the test in the
following format:
function, judgment or status, test voltage, test
current or resistance, test time or ramp time
