RS PRO IIT-2000 - IIT-2000;2010;5000;5010 Specifications

IIT-2000/2010/5000/5010 Instruction Manual/English
05/08/2015 Version No. 001 201
IIT-2000/2010/5000/5010 Specifications
The specifications apply when the IIT-2000/2010/5000/ 5010 is powered on for at
least 30 minutes at 15˚C~35˚C.
Specifications
Environment
Range
Temperature
Humidity
Warranty
15˚C ~ 35˚C
≤70% (No condensation)
Operation
0˚C ~ 40˚C
≤70% (No condensation)
Storage
-10˚C ~ 70˚C
≤85% (No condensation)
Installation Location
Indoors at an amplitude of up to 2000m.
AC Withstanding Voltage
Output Voltage Range
0.100kV~ 5.000kV
Output Voltage Resolution
2V
Output Voltage Accuracy
 (1% of setting +5V) with no load
Maximum Rated Load
200 VA (5kV/40mA) [IIT-2000/2010]
500 VA (5kV/100mA) [IIT-5010/5000]
Maximum Rated Current
40mA [IIT-2000/2010], 100mA [IIT-5010/5000]
0.001mA ~ 10mA(0.100kV≤V≤0.5kV)
0.001mA ~ 40mA(0.5kV<V≤5kV) [IIT-2000/2010]
0.001mA ~ 100mA(0.5kV<V≤5kV) [IIT-5000/5010]
Output Voltage Waveform
Sine wave
Frequency
50 Hz / 60 Hz
