IIT-2000/2010/5000/5010 Instruction Manual/English
208 05/08/2015 Version No. 001
ACCESSORIES
Power cord x1, Quick Start Guide x1
User Manual x1 (CD)
GHT-114x1 for IIT-2000/5000
GHT-114x1, GTL-115x1 for IIT-2010/5010
DIMENSIONS & WEIGHT
IIT-2000/2010: Approx. 330(W) x 148(H) x 452(D) mm (Max.),
19kg(Max)
IIT-5010: Approx. 330(W) x 148(H) x 587(D) mm (Max.),
27kg(Max)
IIT-5000: Approx. 330(W) x 148(H)
x 482(D) mm(Max), 24kg(Max)
Table 1a: Output Limitation in Withstanding Voltage Testing (IIT-2000/2010)
Upper Current
Pause
Output Time
AC
30mA≤I≤40mA
At least as long
as the output
time
Maximum 240 seconds
0.001mA≤I<30
mA
Not necessary
Continuous output possible
DC
0.001mA≤I≤10
mA
Not necessary
Continuous output possible
GB
15A<I≤30A
At least as long
as the output
time
999.9
3A≤I≤15A
Not necessary
999.9
NOTE: Output Time = Ramp Time + Test Time.
Table 1b: Output Limitation in Withstanding Voltage Testing (IIT-5010/5000)
Upper Current
Pause
Output Time
(IIT-2010)
