HIGH VOLTAGE
output terminal
IIT-5000/5010
CAUTION
HIGH VOLTAGE
MAX.
5.0 kVAC
6.0 kVDC
The HIGH VOLTAGE terminal output is used
for outputting the testing voltage.
WARNING
USE EXTREME CAUTION.
Do not touch the HIGH VOLTAGE terminal during testing.
RETURN
terminal
IIT-5000
RETURN
The RETURN terminal is used for IR, DCW
and ACW tests.
RETURN/
SENSE and
SOURCE
terminals
IIT-5010
GB Rx
SENSE H
SOURCE H
SENSE L
SOURCE L
RETURN
HI-POT
IR
The RETURN terminal is used for IR, DCW
and ACW tests.
The SOURCE L/H and SENSE L/H
terminals are for GB tests only.
