IIT-2000/2010/5000/5010 Instruction Manual/English
05/08/2015 Version No. 001 59
The MANU UTILITY settings only apply to the selected MANU
test.
2. Use the UP/DOWN arrow keys to move to the ARC
MODE setting.
3. Use the scroll wheel to set the ARC mode.
OFF, ON AND CONTINUE,
ON AND STOP
4. Press the EDIT/SAVE key to save and exit the
MANU Utility and go back to EDIT status.
I R G B
m A
A CW D C W I / LH O I M ET R
E
F R E Q = 0 H z 6
0
100
k V
0 0 m ARA C = 1 .0
IDE
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0MM A UN N A_
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
T
2M A N U = * * * - 0 0
The ESC key can be pressed at any time in the Utility menu to
cancel and exit.
5. If the ARC MODE was set to either ON AND CONTINUE, or
ON AND STOP, the ARC current level can be edited.
6. Use the UP/DOWN arrow keys to move the cursor
to the ARC setting.
