Name of Each Part
1-21
[12] Solution reservoir
[13] Wash station
Up to 4 wash stations.
[14] Drying station
[15] Heating station
Heating stations permit special stain runs that require heating.
[16] Water supply handle
Use this handle to adjust the water flow rate.
[17] Fume control unit
Activated carbon filters are part of the unit.
[18] Robotic arm
The function of robotic arms is to move slide basket.
[19] CF card slot
This sets a CF card in slot.
[12]
[17]
[18]
[19]
[13]
[14]
[15]
[16]
