Sartorius PR 5220 Series User Manual

J-Bus/ModBus Protocol PR 5220 Instrument Manual
EN-120 Sartorius
Function 3 or 4: Reading n Successive Words
Command Device
address
Function
number
Address of
1st word
Number of
words
1 byte 1 byte 2 bytes 2 bytes
Range 1...127 3, 4 0...63 1...64
Reply Device
address
Function
number
Number of
bytes
Value of the
words
1 byte 1 byte 1 byte n bytes
MSB LSB MSB - - - - - - MSB LSB
1
st
word last word
If the address of one of the words to be read is out of the permissible range (0...63), an error message is sent as
a reply (the address plus the number of bytes must not exceed 64).
Example of function 3 for reading a gross weight (D8 = W16) of 893 kg with ModBus-TCP:
Command 47 12 0 0 0 6 0 3 0 16 0 2
Reply 47 12 0 0 0 7 0 3 4 0 0 3 125
The individual bytes are shown.
