PR 5220 Instrument Manual SMA Protocol
Sartorius EN-127
Requesting the High-Resolution Weight
Command: <LF>R<CR>
Reply: The scale immediately returns the high-resolution (10x) weight and status: Gross weight if not
tared, net weight if tared.
Note: The <n> gross/net status is shown in lower-case letters while the high-resolution weight is
sent.
<LF><s><r><n><m><f><xxxxxx.xxx><uuu><CR>
For details, see page 130.
Requesting the High-Resolution Weight with Stability
Command: <LF>Q<CR>
Reply: The scale returns the weight and the status only, when the stability condition is met: Gross
weight if not tared, net weight if tared.
For this function, the stability condition must be met. The maximum waiting time for stability is
set under [Tare timeout]; see Chapter 4.4.13.
<LF><s><r><n><m><f><xxxxxx.xxx><uuu><CR>
After elapse of the waiting time without reaching stability, the following reply is sent:
<LF><_><1><n><_><f><----------><___><CR>
For details, see page 130.
Requesting the High-Resolution Weight Continuously
This is a command which generates non-requested replies, because it does not function according to the strict
pattern of command and reply. After the command, the scale repeats the reply continuously.
Command: <LF>S<CR>
Reply: The scale repeats the weight and status information continuously until another command is
received.
<LF><s><r><n><m><f><xxxxxx.xxx><uuu><CR>
For details, see page 130.
Dependent on the used baud rate, the repetition rate of reply telegrams is roughly as follows:
19200 bd 100ms
9600 bd 110ms
4800 bd 170ms
Requesting the Tare Weight
Command: <LF>M<CR>
Reply: The scale returns the tare weight and signals the 'tared' status in the <n> status character.
<LF><s><r><T><m><f><xxxxxx.xxx><uuu><CR>
For details, see page 130.
