PR 5220 Instrument Manual Fieldbus Interface
Sartorius EN-143
Register 5: Device Type and Software Release
Only reading is permitted.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 TYPE MSB
Byte 1 TYPE LSB
Byte 2 MAINVERSION
Byte 3 SUBVERSION
E.g. 5220 Rel 1.23 = 52200123
hex
Register 6: Board Number
Only reading is permitted.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Board number MSB
Byte 1 ""
Byte 2 ""
Byte 3 Board number LSB
E.g. 148388723 = 08D83B73
hex
Register 7: (Reserved)
Register 8 ...15: Weight Data
Only reading is permitted.
The gross, net and tare weight are stored as DINT fixpoint.
The real data value is derived from DINT and EXPO as follows :
Value
Real
=reading
DINT
*10
(-EXPO
Register 8 Current gross value
Register 9 Current net value, if tared; otherwise gross
Register 10 Current tare value, if tared, otherwise 0
Register 11 Value on the front-panel display
Register 12 Reserved
Register 13 Reserved
Register 14 Max (FSD)
Register 15 Reserved (free)
Register 24 ... 29: Limit Values (Read/Write)
Register 24 Limit 1 on
Register 25 Limit 1 off
Register 26 Limit 2 on
Register 27 Limit 2 off
Register 28 Limit 3 on
Register 29 Limit 3 off
