SATO E series User Manual

Section 4: Expanded Memory Commands
Page 4-12 SATO Programming Reference
Custom Store
Command Structure <ESC>GIabbbcccddd{data}
a
bbb
ccc
ddd
{data}
=
=
=
=
=
Specifies character format of the data
H Hex data
B Binary data
Number of horizontal 8 x 8 blocks (see Note 7 for
range)
Number of vertical 8 x 8 blocks (see Note 7 for
range)
Graphics storage number (001-099)
Hex or binary data to describe the graphic image
Example: See Appendix C for detailed information on creating
Hex and Binary graphic files.
Placement: Immediately following the <ESC>CC Memory Area
Select command.
Default None
Command Function To provide similar functionality to the <ESC>G Custom Graphic
command, but allows for the graphic image to be stored in Expanded
Memory. Use the Store command to send the graphic data to the
printer, which is held in the optional Expanded Memory, even if printer
power is lost.
Printer Input <ESC>A
<ESC>CC1<ESC>GIH002002001
0100038007C00FE01FF03FF87FFCFFFE07C007
C007C007C007C007C007C007C0
<ESC>Z
Note: See Appendix C for detailed explanation on how to format a
graphics data stream.
Printer Output There is no printer output as a result of this command. See <ESC>GR
Recall Custom Graphics command.

SATO E series Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	6 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Interfaces	USB, Ethernet
Media Type	Labels, Tags, Ticket
Ribbon Length	Up to 984 ft (300 m)
Power Supply	AC 100-240V, 50/60 Hz
Print Resolution	203 dpi
