SICK CLV 45 Series User Manual

Operating Instructions Chapter 6
CLV 45x Bar Code Scanner
Operation
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
6-7
Data string
This tab card and following dialog boxes are used to set the following:
•
Data output format of the host interface
•
Constants and reading diagnosis data in the header, separator and terminator
•
Arrangement of the separators in the data string
•
Output format for no reads and contents of the error string
•
Test string function
•
Output sequence and sort criteria for reading more than one bar code per reading pulse
•
Activating and structure of the format mask
CAN interface
This tab card and following dialog boxes are used to set the following:
•
CAN interface operating mode
•
Data transfer rate
•
Type of logical data connection of the connected CLV
•
Usage of the switching inputs/outputs of the CLV as CANopen Digital I/O
Auxiliary interface
This tab card is used to set the following:
•
Operating mode of the terminal interface
Oscillating mirror
This tab card is used to set the following:
•
Operating mode of the oscillating mirror
•
Oscillating frequency
•
Deflection range (oscillating amplitude)
•
Instant of activity of the oscillation mode referenced to the reading pulse
•
Trigger source for One-Shot
Extras
This tab card is used to edit parameters that were not recognized by CLV-Setup after an
upload.
Note The "CLV-Setup Help" online help contains a detailed description of the functions of the pa-
rameters and their valid entries (for calling the help refer to
Chapter 10.4.6 "CLV-Setup
Help" online help, Page 10-25
).
