SICK CLV 45 Series User Manual

Chapter 10 Operating Instructions
CLV 45x Bar Code Scanner
10-2
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Appendix
10.2 Specification diagrams
10.2.1 Reading conditions for all diagrams
10.2.2 Overview of diagrams
L
Test code Code 39/ITF
Printing ratio 2 : 1
Print contrast > 90 %
Tilt typical
±
30
°
up to focal position 750 mm and resolution 0.35 ...1.0 mm
Ambient light < 2 000 lx
Good read rate > 75 %
Table 10-1: Reading conditions for specification diagrams
CLV type Scanning process Diagram Page
CLV 450-0010 Line scanner Reading ranges about all focal postions 10-3
CLV 450-6010 Line scanner with oscillating mirror Reading ranges about all focal postions 10-4
CLV 450-0010 Line scanner Min. and max. reading distance (DOF) for 0.25 mm 10-5
CLV 450-0010 Line scanner Min. and max. reading distance (DOF) for 0.35 mm 10-6
CLV 450-0010 Line scanner Min. and max. reading distance (DOF) for 0.50 mm 10-7
CLV 450-0010 Line scanner Min. and max. reading distance (DOF) for 1.00 mm 10-8
CLV 450-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 0.25 mm 10-9
CLV 450-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 0.35 mm 10-10
CLV 450-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 0.50 mm 10-11
CLV 450-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 1.00 mm 10-12
CLV 450-0010
CLV 450-6010
Line scanner
Line scanner with oscillating mirror
Characteristics field scanning frequency 10-17
CLV 450-6010 Line scanner with oscillating mirror Deflection range 10-18
CLV 451-0010 Line scanner Min. and max. reading distance (DOF) for 0.50 mm/
aperture angle 25
°
10-13
CLV 451-0010 Line scanner Min. and max. reading distance (DOF) for 0.50 mm/
aperture angle 55
°
10-14
CLV 451-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 0.50 mm/
aperture angle 25
°
10-15
CLV 451-6010 Line scanner with oscillating mirror Min. and max. reading distance (DOF) for 0.50 mm/
aperture angle 55
°
10-16
CLV 451-6010 Line scanner with oscillating mirror Deflection range 10-18
Table 10-2: Overview CLV 45x specification diagrams
