Chapter 5 Operating Instructions
CLV 45x Bar Code Scanner
5-10
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Electrical installation
The wiring of the switching outputs via the AMV/S 40 connection module is described in the
operating instructions "AMV/S 40 connection module" (Order No. 8 008 292, English
edition).
Note In the "Device Ready" function the output delivers a static pulse, if the CLV is in reading
mode.
Hint
The output function, the pulse duration (timer) and the polarity of the signals can be modified
by using the D
EVICE
CONFIGURATION
configuration tab of the CLV-Setup user interface.
¾
Click on the E
DIT
R
ESULT
OUTPUTS
command button. Edit the dialog box.
Recommendation
¾
In order to check the switching functions with a high-resistance digital voltmeter wire a
load to the outputs.
This avoids the display of incorrect voltage values and switching states.
Switching performance PNP-switching against the supply voltage V
S
Properties short-circuit-proof + temperature-protected,
not electrically isolated from V
S
Function assignment
(default setting)
Result 1: "Device Ready (static)", Polarity: Not inverted
Result 2: "Good Read", Polarity: Not inverted
Pulse duration: 100 ms
Electrical values (V
s
–1.5V)
≤
V
O
<V
s
at I
0
≤
100 mA
Table 5-9: Characteristic data of the switching outputs "Result 1" and "Result 2"
