Operating Instructions Chapter 6
CLV 45x Bar Code Scanner
Operation
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
6-31
6.7 Switching off the CLV
1. If the parameter record was modified in CLV-Setup or was only stored temporarily in
CLV via a download, the parameter record must be stored permanently in the CLV by
choosing the P
ERMANENT
storage option.
2. Save the parameter record as a configuration file "*.scl" in CLV-Setup.
3. Switch off the supply voltage of the AMV/S 40 connection module or pull the plug of the
CLV out of the connection module.
The last parameter record stored permanently in the CLV connection module remains valid.
We recommend that you print out the configuration file in order to archive the parameter
record.
1. Click on in the toolbar.
The P
RINT
FILE
dialog box is opened.
2. Enter a comment in the input field in order to assign the printout to the CLV.
Confirm your entry with "OK".
The P
RINT
dialog box for configuring the printer is then displayed.
3. Edit the dialog box correspondingly and confirm.
CLV-Setup prints out the actual configuration file in the form of a table.
