Operating Instructions Chapter 3
CLV 45x Bar Code Scanner
Product description
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
3-3
3.1.4 Design line scanner
Fig. 3-1: Design of the line scanner CLV 45x
Front-end reading window
1
7
5
4
3
2
2
6
Legend:
1
D-Sub HD cable plug, 15-pin
2
Blind hole thread, M 5, 5 mm deep
3
Reading window
4
Laser warning lables
5
Connection cable
6
Sound opening of the beepers (concealed)
7
LEDs (status indicators)
