Chapter 10 Operating Instructions
CLV 45x Bar Code Scanner
10-18
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Appendix
10.2.9 Deflection range of CLV 450 line scanner with oscillating mirror
10.2.10 Deflection range of CLV 451 line scanner with oscillating mirror
Fig. 10-16: CLV 450-6010: Deflection range as a function of the reading distance, the angle of deflection and the resolution
-200
-200
0
200
400
600
800
0 200 400
800 18001000 1200 1400 1600600
20
40
1.0 mm
0.5 mm
0.35 mm
0.25 mm
Deflection range
[mm]
Reading distance [mm]
Fig. 10-17: CLV 451-6010: Deflection range as a function of the reading distance and the angle of deflection at a resolution of 0.5 mm
-200
-200
0
200
400
600
800
0 200 400
800 1000 1200600
20
40
0.5 mm
Deflection range
[mm]
Reading distance [mm]
