Fig. 10-10: CLV 450-6010: Min. and max. reading distance for the line scanner with oscillating mirror as a function of the focal position
at a resolution of 1.00 mm
0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400
0
1800 1600 1700 1500 1400 1200 1300
1100
1000
900 800 700 600 500 400 300 200 100
Reading distance [mm]
Focal position [mm]
CLV 450-6010 (side-end reading window)
Resolution: 1.0 mm
Reading conditions: see Table 10-1, Page 10-2
Characteristics field scanning frequency/reading distance: see Fig. 10-15, Page 10-17 Deflection range: see Fig. 10-16, Page 10-18
Aperture anlge: 50
°
/25
°
max. Leseabstand Öffnungswinkel 25
max. reading distance aperture angle 25
°
max. Leseabstand Öffnungswinkel 25
min. reading distance
max. reading distance*) aperture angle 50
°
Depth of field (DOF) = max. reading distance minus min. reading distance
*) from approx. 820 mm reading distance on the reading field height is limited! See reading range diagram in Fig. 10-2, Page 10-4
