Operating Instructions Chapter 10
CLV 45x Bar Code Scanner
Appendix
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
10-25
10.4.5 Functions
The "CLV-Setup" software from version 3.0 onwards features functions to carry out the fol-
lowing:
•
Loading of the default setting of the parameter record from the database
•
Automatic communication attempt with the CLV when the program is started
•
Automatic software compatibility check in the CLV
•
Uploading parameter record which is stored in the CLV
•
Changing the parameter values in the tab cards
•
CLV Assistant for simple parameterization
•
Saving the changed parameter record to the CLV (download)
•
Saving the changed parameter record in CLV-Setup as a configuration file "*.scl"
•
Printing the configuration files
•
Exporting the configuration files in RTF format
•
Printing the parameter record in the form of Profile bar codes
•
Direct access to the CLV via a terminal emulator (select operating mode, start operating
functions, log file for communication between the CLV and CLV-Setup, extended
terminal mode, e. g. for displaying CLV messages)
•
AutoBaud detect for automatic communication setup with the CLV
•
Selection of the COM ports for adapting the data transfer parameters
•
Monitor for supervising the data communication of the host interface of the CLV
•
Selection menu for the displayed language
•
Selection menu for the units of measure
•
Display of the last 10 edited configuration files
•
Saving the CLV type that was selected last
•
Automatic storage confirmation prompt when changes are made to the configuration
file
•
Assistants for individual device functions
•
Setting switches for starting the program in the "CLVmain.ini" file
•
Hot keys [F keys] for important functions (program use without mouse)
•
Start program with SCL file as an argument
•
Context-specific help via [F1]
10.4.6 "CLV-Setup Help" online help
The "CLV-Setup Help" online help helps you in using the "CLV-Setup" software. The help
runs under an HTML browser (such as Netscape
TM
, Microsoft Internet-Explorer
TM
, or the
I-View Pro
TM
browser supplied with the program). The help can be called up context-specifi-
cally for the parameter being edited and describes the function of the parameter and pos-
sible values for the parameter.
1. Press [F1].
The browser window is opened and displays the help topic.
2. If CLV-Setup cannot find a browser, it asks you to specify the location on the hard disk.
Enter the name of the executable file and the path for the browser in the dialog box
(e. g. Iviewpro32.exe in the "Iview" directory).
3. In order to prevent several browser windows from being opened use the [ALT] + [TAB]
key combination or the Windows status bar to toggle between the CLV-Setup and CLV-
Setup Help applications.
