SICK CLV 45 Series User Manual

Operating Instructions
CLV 45x Bar Code Scanner
Quick Finder
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
E-3
CLV 45x bar code scanner
Quick Finder
•
What is delivered with the device
–
Chapter 3.1.1 Scope of delivery, Page 3-1
•
Caution!
–
Chapter 2 Safety information, Page 2-1
•
Mounting the device at the reading station
–
Chapter 4 Installation, Page 4-1
•
Connecting the device
–
Chapter 5 Electrical installation, Page 5-1
•
Overview of the device and its functions
–
Chapter 3 Product description, Page 3-1
–
Chapter 6.2 Default setting, Page 6-1
–
Chapter 6.5 Operating modes and output of the read result, Page 6-18
–
Chapter 9 Technical data, Page 9-1
•
Starting the device with the default settings
–
Chapter 6.3 Quick-Start, Page 6-3
•
Installing the “CLV-Setup“ user software on the PC
–
Chapter 10.4 Installing and operating the "CLV-Setup" PC software, Page 10-20
•
Adapting the device to the reading application
–
Chapter 6.4 Configuration (parameterizing), Page 6-4
•
Help in cases of problems
–
Chapter 8 Troubleshooting, Page 8-1
•
Finding information
–
Table of contents, Page E-5
–
Chapter 10.16 Index, Page 10-66
