Operating Instructions Chapter 10
CLV 45x Bar Code Scanner
Appendix
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
10-51
replacement device, however, outputs an error message in CLV-Setup for each of these pa-
rameters/values when the parameter records is downloaded.
¾
Check whether all of the parameter settings used are necessary to configure the CLV
for the current reading application. If necessary, replace the software version in the
replacement device.
If the software version on the replacement device is more recent than that on the old one,
the default settings in the imported parameter set will include parameters that were not
contained in the old version.
¾
After an upload from CLV to CLV-Setup check whether the new parameters are relevant
for configuring the CLV for the current reading situation. If necessary, edit the parame-
ters and download the parameter record again to the CLV. Save the new parameter
record as a configuration file in CLV-Setup.
Also refer to
Chapter 10.4.8 Handling unknown parameters, Page 10-26.
10.11 Available accessories
10.11.1 Mounting accessories
10.11.2 Connection modules
Order No. Description Fig.
2 020 410 Mounting bracket, with securing material
Fig. 10-29, Page 10-54
2 022 564 Mounting bracket (formed as a bow), with securing material
Fig. 10-30, Page 10-54
2 023 691 Rod clamp for rods and tubes with 12 ... 20 mm ext. diameter, with securing material
Fig. 10-31, Page 10-55
2 031 342 Mounting bracket with vibration damper, with securing material
Fig. 10-32, Page 10-55
Table 10-10: Available accessories: Mounting accessories
Order No. Type Description
1 017 132 AMV 40-011 Connection module for CLV 45x, with 15-pin D-Sub HD socket, terminal strips (signal distributors)
for connecting the data and function interfaces, internal 9-pin D-Sub "Service" plug, cable grips,
polycarbonate housing, enclosure rating max. IP 54.
Operating voltage 10 ... 30 V DC
1 017 135 AMS 40-013 As AMV 40-011 with additional integrated 230 V AC 50 Hz/24 V DC power pack
1 017 136 AMS 40-012 As AMV 40-011 with additional integrated 115 V AC 50/60 Hz/24 V DC power pack
1 017 385 AMS 40-023 As AMS 40-013, with additional 2-row LCD
2 020 825 – RS 422 to CL 20 mA interface converter, for one CLV, for optional installation in the
AMV 40-011, AMS 40-013, AMS 40-012 and AMS 40-023
1 019 160 AMV 70-081 Connection module for CLV 45x, with 15-pin D-Sub HD socket, spring terminal strips (signal distrib-
utors) for connecting the data and function interfaces, internal 9-pin D-Sub "Service" plug, plastic
cable glands, polycarbonate housing, enclosure rating max. IP 30.
With address function for network operation, operating voltage 10 ... 30 V DC
6 021 105 AMV 100-011 Universal Connection Module for max. two CLVs, for the CLV 45x with 15-pin D-Sub HD socket, ter-
minal strips (signal distributors) for connecting the data and function interfaces, two internal 9-pin
D-Sub "Service" plugs, cable grips, cast aluminium housing, enclosure rating max. IP 54 (enclosure
rating max. IP 65 with connector cover), operating voltage 10 ... 30 V DC
6 021 106 AMV 200-011 As AMV 100, but for four CLV 45x
6 007 655 – Power cable, 3-wire, length 2 m, with 3-pin connector (grounding) and one open end (stripped)
Table 10-11: Available accessories: Connection modules
