SICK CLV 45 Series User Manual

Operating Instructions Chapter 3
CLV 45x Bar Code Scanner
Product description
8 009 139/K949/06-06-2002
©
SICK AG · Division Auto Ident · Germany · All rights reserved
3-1
3
Product description
3.1 Design
3.1.1 Scope of delivery
The packaging of the CLV contains the following:
•
An information sheet (Notes on device) with electrical wiring diagram and Quick-Start
•
An additional set of laser warning lables (self-adhesive) for Class 2 in German/US
English and French/US English
•
A lable with terminal designations for sticking over the connection designations of the
mother board of the AMV/S 40 connection module
Depending on the number of ordered devices one or more technical documentation
sets, consisting of:
•
These CLV 45x operating instructions in English and German
•
A CD-ROM containing the "CLV-Setup" software for Windows
TM
, the "CLV-Setup Help"
online help system and the "I-ViewPro
TM
" HTML browser
•
A foldable card with 12 printed Profile bar codes
Chapter 10.11 Available accessories, Page 10-51
provides an overview of the available
mounting accessories, connection modules, cables and plug-and-socket connections as
well as sensors for reading pulse generation and detection of the object distance.
3.1.2 Device variants
The CLV is available in the following variants:
3.1.3 System requirements
The following are required to start up and operate the CLV:
1. A SICK connection module for power supply and interconnection of the data and
function interfaces.
Available types:
−
AMV 40-011 (No. 1 017 132) for 24 V DC
±
20 %, enclosure rating max. IP 54
−
AMS 40-013 (No. 1 017 135) for 230 V AC 50 Hz/24 V DC, enclosure rating
max. IP 54
−
AMS 40-012 (No. 1 017 136) for 115 V AC 50/60 Hz/24 V DC, enclosure rating
max. IP 54
−
AMV 100-011 (No. 6 021 105) for 10 ... 30 V DC , enclosure rating max. IP 65
−
AMV 200-011 (No. 6 021 106) for 10 ... 30 V DC, enclosure rating max. IP 65
Type
(red light)
Order No. Scanning process Reading
window
CLV 450-0010 1 018 556 Line scanner On front
CLV 450-6010 1 019 218 Line scanner with oscillating mirror Lateral
CLV 451-0010 1 019 522 Line scanner, optimized on 0.5 mm
module width
On front
CLV 451-6010 1 019 524 Line scanner with oscillating mirror,
optimized on 0.5 mm module width
Lateral
Table 3-1: Variants of the CLV 45x
