SICK CLV 45 Series User Manual

Chapter 10 Operating Instructions
CLV 45x Bar Code Scanner
10-6
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Appendix
Fig. 10-4: CLV 450-0010: Min. and max. reading distance for the line scanner as a function of the focal position at a resolution of
0.35 mm
Focal position [mm]
0 100 200 300 400 500 600 700 800 900 1000
0
100 200 300 400 500 600 700 800 900
1000
1100
1200
CLV 450-0010 (front-end reading window)
Reading distance [mm]
Characteristics field scanning frequency/reading distance: see Fig. 10-15, Page 10-17
Depth of field (DOF) = max. reading distance minus min. reading distance
Resolution: 0.35 mm
Reading conditions: see Table10-1, Page10-2
Aperture anlge: 50
°
/25
°
*) from approx. 620 mm reading distance on the reading field height is limited! See reading range diagram in Fig. 10-1, Page 10-3
max. Leseabstand Öffnungswinkel 25
max. reading distance aperture angle 25
°
max. Leseabstand Öffnungswinkel 25
min. reading distance
max. reading distance*) aperture angle 50
°
