Chapter 9 Operating Instructions
CLV 45x Bar Code Scanner
9-2
©
SICK AG · Division Auto Ident · Germany · All rights reserved 8 009 139/K949/06-06-2002
Technical data
9.2 Data sheet CLV 45x line scanner with oscillating mirror
Technical data such as line scanners, however, with the following deviations
Enclosure rating/Protection class IP 65 (to DIN 40 050)/Class 3 (to VDE 0106/IEC 1010-1)
EMC/Vibration/Shock test To EN 50081-2, EN 50082-1, EN 61000-6-2/to EN 61010-1/to EN 60068-2-27
Weight 530 g with connection cable
Ambient operating/storage temperature 0 ... +40
°
C/ –20 ... +70
°
C
Max. relative humidity 90 %, non-condensing
1) (default setting), in reading mode at the pulsing mode "Switching input Sensor 1" and "Serial interface"
2) DC = Distance configuration (limitation of the active evaluation range of the scan line by selection of the min. and max. value of the code position)
3) Reading interval: Time window of the code evaluation generated by the reading pulse
4) Standard decoder: Additionally pharmacode
5) SMART decoder: Code 39: Max. 30 characters. Code bar: Max. 30 characters. Code 128, EAN 128: Max. 48 characters (max. 96 "half-characters").
Code 93: Max. 47 characters
Type CLV 450-0010 CLV 451-0010
Table 9-1: Technical specifications line scanner
Type CLV 450-6010 CLV 451-6010
Reading window Lateral
Light emission At an angle of 105
°
(neutral position CW = 50)
Trigger source for DC changeover
6)
Additionally Oscillating mirror extrema
Effective opening angle Max. 50
°
Oscillating mirror functions
Fixed (position adjustable)/oscillating (amplitude per DC variable or fixed)/One-Shot
7)
Oscillating frequency 0.5 ... 4 Hz
Max. deflection angle +20
°
... –20
°
(can be set per software)
Reading ranges Refer to Chapter 10 Appendix, Page 10-1
Deflection ranges Refer to Fig. 10-16, Page 10-18
Operating voltage/power consumption 10 ... 30 V DC/max. 7.2 W
Weight 700 g with connection cable
6) DC = Distance configuration (limitation of the active evaluation range of the scan line by selection of the min. and max. value of the code position as well as the oscillating
amplitude by selecting the CW value)
7) One-Shot: Single oscillating movement per reading pulse (starting position and speed for forward and reverse movement can be selected)
Table 9-2: Technical specifications line scanner with oscillating mirror
